Rejection Style Design Prevents Replacement Errors When Used with Recommended Fuse Blocks; Fiberglass Body Provides Dimensional Stability in Harsh Industrial Environments; Versatile Design for Individual Component and Branch Circuit Protection 600 VAC/VDC, 15 A, Ferrule Terminal, Class CC Rejection, Fast Acting, Midget Fuse Body Material Glass-Melamine Laminate; Contact Material Tin Plated Copper; Mounting Type Clip; Application Control Circuits, Lighting, General Loads, Branch Circuit Protection
Midget Fuse; Type Class CC Rejection; Characteristics Fast Acting; Voltage Rating 600 VAC/VDC; Current Rating 15 Ampere; Interrupting Rating 200 Kiloampere (AC)/100 Kiloampere (DC); Terminal Type Ferrule; Diameter 0.41 Inch; Length 1.5 Inch; Approval UL 248-4, CSA C22.2; Body Material Glass-Melamine Laminate; Contact Material Tin Plated Copper; Mounting Type Clip; Application Control Circuits, Lighting, General Loads, Branch Circuit Protection
Amp-Trap ATMR fast-acting fuses are the smallest dimension 600V fuses suitable for branch-circuit protection. The ATMR is a popular choice for economical protection of control circuits and control circuit transformers where available short circuit currents exceed 10,000 amperes. ATMR's rejection dimensions prevent substitution by lesser rated fuses. These fast-acting fuses give current-limiting protection to general circuits.
Specs
- Condition: Brand New
- Brand: Mersen
- Item ID: ATMR15
- Manufacturer: Mersen
- Product Type: Midget Fuse
Document Downloads
Additional Part Number Information:
- Equivalent Part Number: ATMR15
- Supplies Depot Part Number: 27648
