Smooth Jacket Eliminates Snagging and Tearing; PVC Jacket, Polypropylene Insulation Ensures Excellent Strip Ability; Sunlight Resistant Jacket 0.17 inch x 250 feet, 150 V, 18 AWG Solid, 5-Conductor, Brown PVC Jacket, Bare Copper, Reel, CL2/CMH/FT1, Thermostat Wire Applicable Standard NEC 725; Insulation Thickness 0.006 Inch; Insulated Conductor Diameter 0.052 Inch; Jacket Thickness 0.015 Inch; Application Thermostats, Air-Conditioning Controls, Other Low Voltage Remote Control Circuits, Doorbells, Alarm Systems
Thermostat Wire; Type CL2/CM/CMH/FT1; Voltage Rating 150 V; Conductor Material Bare Copper; Conductor Size 18 AWG; Number of Conductors 5; Jacket Color Brown; Stranding Solid; Jacket Material PVC; Insulation Material Polypropylene; Color Code Red, White, Green, Blue, Yellow; Temperature Rating -20 to 60 Deg C; Length 250 Ft; Outer Diameter 0.17 Inch; Weight 31 Lb/MFt; Package Type Reel; Approval UL, ETL (Canada and US); ROHS Compliant; Applicable Standard NEC 725; Insulation Thickness 0.006 Inch; Insulated Conductor Diameter 0.052 Inch; Jacket Thickness 0.015 Inch; Application Thermostats, Air-Conditioning Controls, Other Low Voltage Remote Control Circuits, Doorbells, Alarm Systems
Specs
- Condition: Brand New
- Brand: Coleman Cable
- Item ID: 553050407
- Manufacturer: Coleman Cable
- Product Type: Thermostat Wire
Document Downloads
Additional Part Number Information:
- Equivalent Part Number: 553050407
- Supplies Depot Part Number: 25491
